After many open hardware projects with LoRa (see https://hackaday.io/project/196814-rp2040-minipill-lora) , we are currently developing an open source and hardware platform for FWs. It’s truly a community-driven project for the community. Interested in this project? Then feel free to contact us! We’re looking for contributors for PCB design and reviewing as well as software development. #pcb #KiCad #openHardware #openSource

KiCad folks: Is there a way to make alternate symbols in a multi-unit symbol? I'm making tube symbols in the style of Tektronix (and others) where the A & B units of a Dual Triode would have half the envelope shown. If I flip one so the grid is coming out the other side, my half circle envelop will be facing the wrong way. If I made them separate symbols, they couldn't share a single footprint, right?Is there a less dumb way than making 4 versions of this symbol with each combination? #Kicad

#KiCad 10.0 PCB Design and Electronics CAD Software Released as a Major Update https://9to5linux.com/kicad-10-0-pcb-design-and-electronics-cad-software-released-as-a-major-update@kicad #OpenSource #FreeSoftware #Linux #CAD

@cccpresser woot! I'm super excited about the new design blocks
